rain recovery system

by nbcorp - uploaded on April 14, 2011, 8:10 pm

Simple diagram of a system for storing rainwater.

A: gutter - B: strainer - C: grid - D: mobile lock - E: sewer - F: control and cleaning plug - G: access plug - H: grid - I: water tank.

Log in to add this clipart to a collection.

Tags
hydrology rain tank water water treatement
