Resistor (metal film)

by Adrian - uploaded on July 28, 2016, 9:17 pm

The image can be used in a script, e.g. resistance calculator. Human-readable path names, such as outline, bg1, endoflead1, cml1 (colour marking line), c1 (colour1) etc.

Useful to know:

• Blue bg (metal-film) is #729FCF

• Sandy bg (carbon-film) is #FFCC66
