9 V battery with clip and short circuit
by mathias_magdowski - uploaded on October 21, 2018, 6:40 pm
This is a plain 9 V battery with a clip to connect it to some electric circuit. The red and the black wire are short-circuited. This should usually not happen, as it will discharge the battery and heat it up.
