Battery Clip for a 9 V Battery with Polarity
by mathias_magdowski - uploaded on October 21, 2018, 6:53 pm
This is a battery clip to connect a 9 V battery to some electric circuit using a red and a black wire. The polarity of the wires is additionally shown by a + for the plus pole and a - for the minus pole.
