DIN A4 technical drawing format
- Sheet layout of A4 sized technical drawings.
The paper size is DIN 823 and ISO 216 compatible -"the A series".
The layout is ISO 5457 compatible.
Other standards to handle with care: ISO 838 for filing holes and ISO 7200 for title block.
