red led with 9 V battery

by mathias_magdowski

2018-10-21 19:24:55

This is a plain red light-emitting diode with 5 mm diameter and straight wire connectors powered by a 9 V battery using a battery clip for connection. Please note that this only works, if the led features some internal series resistor to limit the forward current.

Tags
remix+308631 remix+308622 remix+308623 remix+308624 battery 9 volt 9 V batterie cell industrial cell professional alkaline battery alkaline battery clip Batterieclip cable stranded wire wire flexible wire led light-emitting diode wire reflector
Safe for Work?
Yes
