DIN A technical drawing formats and their folding

by Lazur URH

2014-09-08 19:58:50

Sheet layouts of 2A0 to A4 sized technical drawings. The paper sizes are DIN 823 and ISO 216 compatible -"the A series". The layouts are ISO 5457 compatible. Other standards to handle with care: ISO 838 for filing holes and ISO 7200 for title block.

Tags: 2014, 2A0, A0, A0.00, A1, A1.0, A1.00, A2, A2.0, A2.00, A2.1, A3, A3.0, A3.00, A3.1, A3.2, A4, DIN, DIN 823, DIN 824, ISO, ISO 216, ISO 5457, ISO 7200, ISO 838, Lazur, URH, architecture, drafting, drawing, engineering, filing, folding, layout, planning, sheet, size, technical, template,

Safe for Work? Yes
