cube

by Lazur - uploaded on August 22, 2016, 4:14 pm

A cube with 1m edge in an ortographic projection where x, and y axises are aligned to 22° and 40° from the horizontal. (In 1:1 scale @90 dpi.)



With three other views that show the faces in their true size -which are parents.



With a fancy little metal finish in horizontal direction.
